Overview Quick info:Model Name: Lithium metal battery, Primary lithium battery, Non-rechargeable lithium batteryType: ER;
Overview
. Netural labels,PVC,Corrugated box, Pallet,Customised package . 1200pcs per carton, G.W. 13.0KGS. . Delivery Detail:sample within 3 work days,7~15 days for bulk order
Application
1. Water meter, Gas meter, Ammeter.2. Memory power for many instument and meter equipment.3. Iot products.
Product Advantages
1. High-voltage 3.6V.2. The specific energy(500wh/kg) and energy density(1000wh/dm) are very high.3. The discharge voltage is very stable.4. Wide working temperature range (-55ºC~+85ºC).5. Self-discharge is very low, the shelf-life can be more than 10years.
Spotlight:
1). Provide both single cells and battery packs. 2). 100% inspection before delivery. 3). Inspects appearance, size, OCV&CCV. 4). Manufacturer of all types of primary ltihium battery and rechargeable lithium battery. 5). Established quality control systems under ISO9001 6). Supply battery with different pins, wire&connectors.
Shipping terms:
1).Samples checking: sending by Express ( DHL/UPS/FEDEX/Euro special line/,by air)
2).Bulk production: By ocean,or we can accept other shipping terms according to your requirements. 3).We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:
1).Do not throw battery, fire or make it wet;
2).Keep the battery away from heat source(like fire or heater); 3).Do not throw the battery into fire or heat the battery;
4).Forbid to hammer to trample the battery; 5).Forbid disassembling the battery in anyway 6). Do not charge the battery, make it short-circuit, crush, over-discharge, heat above 212ºF (100ºC).
Call us to know more details datasheet.Detailed Photos
Product Parameters
Basic Info.
| Model NO. | ER14250M |
| Weight | 11g |
| Original | China Hubei Wuhan |
| Delivery Time | 15 to 20days |
| Nominal Voltage | 3.6V |
| Nominal Capacity | 800mAh |
| Self Discharge Rate | Less Than 1% |
| Shelf Life | More Then 10years |
| Transport Package | Plastic Tray and Carton |
| Specification | 14.5 (D)X 25.0 (H)mm |
| Trademark | LISUN/OEM |
| Origin | China |
| HS Code | 8506500000 |
| Production Capacity | 5million Per Month |
Product Description
Quick info:Model Name: Lithium metal battery, Primary lithium battery, Non-rechargeable lithium batteryType: ER14250MBrand Name: LISUN/OEMNominal capacity (at2mA -2V): 800mAhNomial voltage:3.6VMax.constant current: 100mAMax. Pulse current: 150mAOperating temperature range: -55ºC~+85ºCPlace of Origin: Wuhan, China (Mainland)Certificate:CE,ROHS,UN38.3 REACHSize:14.5(D) x 25.0(H)mmWeight:11gDelivery time:7-15daysWarranty:12 months Packing: plastic tray and standard export carton/customized Packaging & Delivery :. Netural labels,PVC,Corrugated box, Pallet,Customised package . 1200pcs per carton, G.W. 13.0KGS. . Delivery Detail:sample within 3 work days,7~15 days for bulk order
Application
1. Water meter, Gas meter, Ammeter.2. Memory power for many instument and meter equipment.3. Iot products.
Product Advantages
1. High-voltage 3.6V.2. The specific energy(500wh/kg) and energy density(1000wh/dm) are very high.3. The discharge voltage is very stable.4. Wide working temperature range (-55ºC~+85ºC).5. Self-discharge is very low, the shelf-life can be more than 10years.
Spotlight:
1). Provide both single cells and battery packs. 2). 100% inspection before delivery. 3). Inspects appearance, size, OCV&CCV. 4). Manufacturer of all types of primary ltihium battery and rechargeable lithium battery. 5). Established quality control systems under ISO9001 6). Supply battery with different pins, wire&connectors.
Shipping terms:
1).Samples checking: sending by Express ( DHL/UPS/FEDEX/Euro special line/,by air)
2).Bulk production: By ocean,or we can accept other shipping terms according to your requirements. 3).We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:
1).Do not throw battery, fire or make it wet;
2).Keep the battery away from heat source(like fire or heater); 3).Do not throw the battery into fire or heat the battery;
4).Forbid to hammer to trample the battery; 5).Forbid disassembling the battery in anyway 6). Do not charge the battery, make it short-circuit, crush, over-discharge, heat above 212ºF (100ºC).
Call us to know more details datasheet.Detailed Photos
| Our company |
| Our Certification |
Product Parameters
| Model | Nominal Voltage (V) | Nominal Capacity (mAh) | Standard discharge current (mA) | End Voltage (V) | Test Temperature | Max. diameter (mm) | Max. Height (mm) | Reference Weight (g) |
| ER13150 | 3.6 | 450 | 0.5 | 2.00 | 23±3 | 13.5 | 15.0 | 5.5 |
| ER14250 | 3.6 | 1200 | 0.5 | 2.00 | 23±3 | 14.5 | 25.0 | 10 |
| ER14335 | 3.6 | 1600 | 1 | 2.00 | 23±3 | 14.5 | 33.5 | 12 |
| ER14505 | 3.6 | 2400 | 2 | 2.00 | 23±3 | 14.5 | 50.5 | 19 |
| ER17505 | 3.6 | 3200 | 1 | 2.00 | 23±3 | 17.0 | 50.5 | 26 |
| ER18505 | 3.6 | 4000 | 1 | 2.00 | 23±3 | 18.5 | 50.5 | 28 |
| ER26500 | 3.6 | 9000 | 2 | 2.00 | 23±3 | 26.2 | 50.0 | 52 |
| ER34615 | 3.6 | 19000 | 3 | 2.00 | 23±3 | 34.2 | 61.5 | 100 |
| ER4250M | 3.6 | 800 | 2 | 2.00 | 23±3 | 14.5 | 25.5 | 11 |
| ER14335M | 3.6 | 1300 | 2 | 2.00 | 23±3 | 14.5 | 34.1 | 13 |
| ER14505M | 3.6 | 2200 | 1 | 2.00 | 23±3 | 14.5 | 50.5 | 20 |
| ER17505M | 3.6 | 2600 | 4 | 2.00 | 23±3 | 17 | 50.5 | 27 |
| ER18505M | 3.6 | 3600 | 4 | 2.00 | 23±3 | 18.5 | 50.5 | 29 |
